These Single mode 12 fiber ribbon pigtails with 900 micron buffer are ready for splicing. Each fiber strand in the kit has a color-coded buffer for easy identification and the colors are industry standard. In this 12-pack, twelve strands of fiber are terminated on one end with LC connectors. Connectors are ceramic with Ultra physical contact (UPC) finish. Each cable comes with test results and a lifetime guarantee.
Fiber pigtails are a great solution for fusion splicing inside of a fiber optic enclosure. The ribbon fan-out fiber pigtails come with a partial outer jacket to help protect the tight buffer fibers from being damaged. If space is a premium, the outer jacket can easily be removed, allowing the pigtails to have a tighter bend radius and take up less space.
Specification:
|
Item |
SM (Single-Mode) |
MM (Multimode) |
|||
|
Fiber Cable Type |
G625D/G655/G6571A/G657A2 |
OM1 |
OM2/OM3/OM4 |
||
|
Fiber Diameter (um) |
9/125 |
62.5/125 |
50/125 |
||
|
IL (dB) |
≤0.3 |
≤0.1 |
|||
|
Cable Type |
Simplex, Duplex, Fan-Out |
||||
|
Connector Type |
LC, SC, FC, ST, MU, MPO, MTRJ, D4, DIN, SMA, FDDI, |
||||
|
Cable OD (um) |
0.9/1.6/1.8/2.0/2.4/2.8/3.0 |
||||
|
End-face Type |
PC |
UPC |
APC |
UPC |
UPC |
|
Retun Loss(dB) |
>45 |
>50 |
>60 |
/ |
|
|
Insert-pull Test (dB) |
<0.2 |
<0.3 |
<0.15 |
||
|
Interchangeability (dB) |
<0.1 |
<0.15 |
<0.1 |
||
|
Mating Times |
>1000 |
||||
|
Anti-tensile Force (N) |
>70 |
||||
|
Temperature Range (℃) |
-40~+80 |
||||
LC/APC Single Pigtails Specification:
|
Parameter |
Unit |
Index |
|||
|
End-Face Type |
|
PC |
UPC |
APC |
|
|
IL |
dB |
SM: ≤0.3;MM ≤0.1 |
|||
|
Repeatability |
dB |
≤0.1 |
|||
|
Interchangeability |
dB |
≤0.2 |
|||
|
RL |
SM |
dB |
≥45 |
≥50 |
≥60 |
|
MM |
dB |
≥36(Exclusive APC connector) |
|||
|
Mating Times |
|
＞1000 |
|||
|
Operating Temperature |
℃ |
-40~ +80 |
|||
Features of Ribbon Pigtail:
• Low insertion loss and back reflection loss
• Good exchangeability
• High-temperature stability
• LSZH sheath (low smoke zero halogens)
• Each packaging unit includes a test chart for each fiber
• 900μ fibers in red, green, blue, yellow, white, gray, brown, purple, turquoise, black, orange, pink
• 100% inspected for optical characteristics before shipment
• Boots in a variety of colors
Application
• Optical fiber access networks
• Optical fiber CATV
• Optical fiber test equipment
